MSI PRO Z890-S WIFI DDR5 Motherboard – Used
₨54,999.00
MSI PRO Z890-S WIFI DDR5 Motherboard – Used
About this item
- Intel Core Ultra Ready
- DDR5 Memory Support
- Form Factor: ATX
Warranty!
6 Months Warranty
Description
Specifications
| Specification | Details |
|---|---|
| Chipset | INTEL Z890 |
| CPU | Supports Intel® Core™ Ultra Processors (Series 2) LGA 1851 |
| Memory | 4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support: 8800 – 6400 (OC) MT/s / 6400 – 4800 (JEDEC) MT/sMax. Overclocking: • 1DPC 1R: Max speed up to 8800+ MT/s • 1DPC 2R: Max speed up to 7200+ MT/s • 2DPC 1R: Max speed up to 6400+ MT/s • 2DPC 2R: Max speed up to 5600+ MT/s Supports Intel® POR Speed and JEDEC Speed DIMM slots feature double-sided latches. |
| Onboard Graphics | 1x HDMI™ — Supports HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort — Supports DisplayPort 1.4, maximum resolution of 4K 60Hz* 1x Type-C DisplayPort — Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, maximum resolution of 4K@120Hz / 8K@60Hz**Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| Slot | 4x PCI-E x16 slot PCI_E1: PCIe 5.0, supports up to x16 (From CPU) PCI_E2: PCIe 3.0, supports up to x1 (From Chipset) PCI_E3: PCIe 4.0, supports up to x4 (From Chipset) PCI_E4: PCIe 4.0, supports up to x4 (From CPU) |
| Audio | Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
| Storage | 3x M.2 M.2_1: Source from CPU, supports up to PCIe 5.0 x4, supports 2280/2260/2242 devices M.2_2: Source from Chipset, supports up to PCIe 4.0 x4, supports 2280/2260/2242 devices M.2_3: Source from Chipset, supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G*Please refer to the manual for M.2 SSD heatsink restrictions. |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices |
| Onboard Thunderbolt | 1x Thunderbolt 4 port (Rear) Supports up to 40Gbps transfer rate with Thunderbolt devices Supports up to 20Gbps transfer rate with USB4 devices Supports up to 10Gbps transfer rate with USB 3.2 devices Supports up to 5V/3A, 15W power charging Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices Supports up to 8K display |
| USB | 4x USB 2.0 (Front) 6x USB 5Gbps Type-A (Rear) 2x USB 5Gbps Type-A (Front) 1x USB 20Gbps Type-C (Rear) 1x USB 20Gbps Type-C (Front) |
| LAN | Realtek® 8125D 2.5Gbps LAN |
| Internal IO | 1x Thunderbolt 5 card connector (JTBT5, support RTD3) 1x Power Connector (ATX_PWR) 2x Power Connector (CPU_PWR) 1x Power Connector (PCIE_PWR 8-pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector (JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector (JRGB) 1x TPM pin header (Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type-A ports 1x USB 20Gbps Type-C port |
| WIRELESS LAN & BLUETOOTH | Intel® Wi-Fi 7 Wireless module pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/b/g/n/ac/ax/beSupports Bluetooth® 5.4**, MLO, 4KQAM *6GHz band support may depend on each country’s regulations. Wi-Fi 7 will be ready in Windows 11 version 24H2. |
| LED FEATURE | 4x EZ Debug LED |
| OPERATING SYSTEM | Support for Windows® 11 64-bit |
| PCB Info | ATX 243.84mm x 304.8mm |
Why Choose MSI PRO Z890-S WIFI DDR5 Motherboard?
The MSI PRO Z890-S WIFI DDR5 Motherboard is a practical choice for users building a modern Intel desktop with a focus on performance, connectivity, and long-term upgrade flexibility. Its Z890 chipset platform supports compatible Intel Core Ultra processors, while DDR5 memory support helps deliver fast and efficient system performance. With built-in WiFi connectivity and a range of modern expansion and connectivity options, it provides a well-rounded foundation for gaming, productivity, content creation, and professional PC builds.
For further details, visit official website.
“TechMatched offers a price-match policy for its customers. If you find anyone selling at less price than us, you can simply contact us and we’ll match the price for you.
Read here in detail about Price-Match Policy.”
Additional information
| Weight | 1 kg |
|---|---|
| Warranty | 6 Months |
