Buy Intel Arc B580 12GB Graphic Card in Pakistan | TechMatched

Intel Arc B580 Challenger 12GB OC, DirectX Support, AV1 Encode/Decode

About this item

• Graphics Clock  2670 MHz
• GPU Peak TOPS (Int8)  233
• Render Slices 5
• Tracing Units 20

Intel Arc B580 12GB Graphic Card

Intel Arc B580

The Arc B580 is a performance-segment graphics card by Intel, launched on December 12th, 2024. Built on the 5 nm process, and based on the BMG-G21 graphics processor, in its SRPMF variant, the card supports DirectX 12 Ultimate. This ensures that all modern games will run on Arc B580. Additionally, the DirectX 12 Ultimate capability guarantees support for hardware-raytracing, variable-rate shading and more, in upcoming video games. The BMG-G21 graphics processor is an average sized chip with a die area of 272 mm² and 19,600 million transistors. It features 2560 shading units, 160 texture mapping units, and 80 ROPs. Also included are 160 tensor cores which help improve the speed of machine learning applications. The card also has 20 raytracing acceleration cores. Intel has paired 12 GB GDDR6 memory with the Arc B580, which are connected using a 192-bit memory interface. The GPU is operating at a frequency of 2670 MHz, which can be boosted up to 2670 MHz, memory is running at 2375 MHz (19 Gbps effective).
Being a dual-slot card, the Intel Arc B580 draws power from 1x 8-pin power connector, with power draw rated at 190 W maximum. Display outputs include: 1x HDMI 2.1a, 3x DisplayPort 2.1. Arc B580 is connected to the rest of the system using a PCI-Express 4.0 x8 interface. The card’s dimensions are 272 mm x 115 mm x 45 mm, and it features a dual-slot cooling solution.



Specifications

Xe-cores

20

Render Slices

5

Ray Tracing Units

20

Intel® Xe Matrix Extensions (Intel® XMX) Engines

160

Xe Vector Engines

160

Graphics Clock

2670 MHz

GPU Peak TOPS (Int8)

233

TBP (Total Board Power)

190 W

PCI Express Configurations

PCI Express 4.0 x8

Device ID

0xE20B

Memory Specifications

Memory

12 GB GDDR6

Graphics Memory Interface

192 bit

Graphics Memory Bandwidth

456 GB/s

Graphics Memory Speed

19 Gbps

I/O Specifications

# of Displays Supported

4

Graphics Output

HDMI 2.1, DP 2.1 up to UHBR 13.5, DP 2.1 up to UHBR 10

HDMI Variable Refresh Rate (VRR)

Yes

VESA Adaptive Sync

Yes

Media Profiles

HDR10, HDR10+ Gaming, Dolby Vision

Max Resolution (HDMI)

7680 x 4320 @ 120Hz

Max Resolution (DP)

7680 x 4320 @ 60Hz

Features

H.264 Hardware Encode/Decode

Yes

H.265 (HEVC) Hardware Encode/Decode

Yes

AV1 Encode/Decode

Yes

VP9 Bitstream & Decoding

Yes

Supported Technologies

Ray Tracing

Yes

oneAPI Support

Yes

OpenVINO™ Support

Yes

DirectX Support*

DirectX 12 Ultimate

Vulkan Support*

1.3

OpenGL Support*

Up to 4.6

OpenCL Support*

3.0

Multi-Format Codec Engines

2

Intel® Extension for PyTorch (IPEX) Support*

Yes

Intel® Xe Super Sampling (XeSS) Support

Yes

Intel Reference Card Attributes

Dimensions (Length x Width)

272 x 115 mm

Slots

2

Weight

779 g

Minimum Power Supply Unit

600 W

Power Connectors

1 x 8-pin
