Buy Asus Rog Strix Z690-I Gaming Wifi DDR5 Motherboard in Pakistan | TechMatched
Intel® Z690 LGA 1700 ITX motherboard with PCIe® 5.0, 10+1 power stages, Two-Way AI Noise Cancelation, AI Overclocking, AI Cooling, AI Networking, WiFi 6E (802.11ax), Intel® 2.5 Gb Ethernet, two M.2 slots with heatsinks and backplates, two Thunderbolt™ 4 USB Type-C®, SATA and Aura Sync RGB lighting
- Intel® LGA 1700 socket: Ready for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors
- Optimal Power Solution: 10+1 power stages with ProCool II power connector, high-quality alloy chokes and durable capacitors to support multi-core processors
- Optimized Thermal Design: Integrated I/O cover and VRM heatsinks with high conductivity thermal pad, L-shaped heatpipe, two onboard M.2 heatsinks and backplates
- High-performance Networking:On-board Intel® WiFi 6E (802.11ax) and Intel® 2.5 Gb Ethernet with ASUS LANGuard
- Best Gaming Connectivity: Supports HDMI® 2.1, two M.2 slots, 2 x ThunderboltTM 4 as well as 1 x USB 3.2 Gen 2×2 Type-C®
- Intelligent Control: ASUS-exclusive AI Overclocking, AI Cooling, AI Networking and Two-Way AI Noise-Cancelation to simplify setup and improve performance
- DIY Friendly Design: Bundled ROG Front Panel SATA Card, M.2 Q-Latch, Pre-mounted I/O shield, BIOS FlashBack™ button, and Clr CMOS button
- Unmatched Personalization: ASUS-exclusive Aura Sync RGB lighting, including a RGB header and two addressable Gen 2 headers
- Industry-leading Gaming Audio: ALC4080 with Savitech SV3H712 amplifier, along with DTS® Sound Unbound and Sonic Studio III
- Renowned Software: Bundled AIDA64 Extreme 60 days free trial version and intuitive UEFI BIOS dashboard with integrated MemTest86
Asus Rog Strix Z690-I
The ROG Strix Z690-I Gaming WiFi packs premium-grade power delivery and triple-decker cooling into a compact mini-ITX form factor to unleash the full force of 14th or 13th or 12th Gen Intel® Core™ processors. Meanwhile, cutting-edge performance arrives courtesy of a PCIe® 5.0 expansion slot and DDR5 memory support.
Specification:
| CPU Support |
Intel® Turbo Boost Technology 2.0, Intel® Turbo Boost Max Technology 3.0 (CPU dependent) |
| Memory |
2 x DIMM, Max. 96GB, DDR5 6400+(OC) to 4800, Dual Channel, Non-ECC Un-buffered, Intel® XMP support, OptiMem II |
| Graphics |
1 x HDMI port, 2 x Intel® Thunderbolt™ 4 ports |
| Expansion Slots |
1 x PCIe 5.0 x16 (depends on CPU), Intel® Core™ 14th/13th/12th Gen |
| Storage |
2 x M.2 (PCIe 4.0 x4 / SATA), 4 x SATA 6Gb/s (via ROG Front panel card), Intel® RST RAID 0/1/5/10 |
| Ethernet |
1 x Intel® 2.5Gb Ethernet |
| Wireless & Bluetooth |
Intel® Wi-Fi 6E (2×2), Bluetooth v5.2 |
| Rear USB Ports |
2 x Thunderbolt™ 4 (USB-C), 2 x USB 3.2 Gen 2 (Type-A), 3 x USB 3.2 Gen 1 (Type-A), 2 x USB 2.0 (Type-A) |
| Front USB Ports |
1 x USB 3.2 Gen 2×2 (Type-C), 1 x USB 3.2 Gen 1 header (2 ports), 1 x USB 2.0 header (2 ports) |
| Audio |
ROG SupremeFX 7.1 ALC4080, 120dB SNR, Savitech AMP, LED audio jacks, Optical S/PDIF out |
| Back I/O Ports |
USB (as above), 1 x HDMI, 1 x Ethernet, Wi-Fi Module, Optical S/PDIF, Audio jacks, BIOS FlashBack™, Clear CMOS |
| Internal I/O |
2 x M.2, 4 x SATA (w/ accessory), 1 x USB 3.2 Gen 2×2, 1 x USB 3.2 Gen 1 header, 1 x USB 2.0 header, AIO/CPU/Chassis fan headers, RGB/ARGB headers, Power_BTN, etc. |
| Special Features |
M.2 Q-Latch, Q-LED, SafeSlot, Pre-mounted I/O, BIOS FlashBack™, Clear CMOS, ProCool II, AURA Sync, Extreme Engine Digi+ |
| Software |
ROG GameFirst VI, Sonic Studio, Sonic Radar, DTS Sound Unbound, Armoury Crate, AI Overclocking, Fan Xpert 4, MyASUS, AI Suite 3, WinRAR, UEFI BIOS tools, MemTest86 |
| BIOS |
256 Mb UEFI AMI BIOS |
| Manageability |
WOL by PME, PXE |
| Accessories |
Wi-Fi antenna, USB2.0 splitter, SATA cables, Cable ties, M.2 Q-Latch, ROG stickers/keychain, Support DVD, User guide |
| OS Compatibility |
Windows® 11 64-bit, Windows® 10 64-bit |
| Form Factor |
Mini-ITX (17cm x 17cm) |
For further details, visit official website.
